Description

This product adopts IoT communication and has an acoustic-optic alarm function, mainly used to provide acoustic-optic prompts for on-site personnel in emergency scenarios. It can be used with various products and systems, such as infrared detectors, door magnets, window magnets, smoke detectors, gas detectors, carbon monoxide detectors, water leakage detectors, temperature detectors, humidity detectors, security alarm hosts, fire alarm hosts, elderly care systems, etc.

Main Features

1. Communication Modes: CAT.1

2. Power Supply: 110V-220V.

3. Alarm Methods: Sound + flashing light.

4. Power Plugs: GB/EU/UK standards.

5. Antenna: Dedicated CAT.1 antenna. Resonance adjustment technology and anti-metal wave absorption technology reduce the impact of the door frames and PCB circuits on antenna reception sensitivity.

6. ADST Technology: Through intelligent analysis, ensures 100% successful alarm signal transmission when CAT.1 signals are weak, while minimizing power consumption.

7. Heartbeat Function: Adjustable heartbeat interval; indicates communication disconnection.

8. Indicator Functions: CAT.1 signal strength indication, signal transmission indication, and self-check indication.

9. Warning Functions: CAT.1 module fault warning, CAT.1 card fault warning, signal transmission failure warning, base station connection failure warning, platform communication failure warning, and low voltage warning.

10. Signal strength testing.

11. Adjustable alarm duration: 30s/5min/15min/30min.

12. Adjustable alarm volume.

Installation and Operation Instructions

1. Product IMEI Registration on Cloud Platform

Scan the code or enter the IMEI directly via the APP, or PC management terminal to add the device to the cloud platform. Operations may vary by platform. This can be completed by the manufacturer before shipment, centrally by engineers, or on-site. Refer to the cloud platform operation manual.

2. On-Site Installation and Testing

1. Insert the NB-IoT card

(Choose Unicom, Telecom, or Mobile based on local signal strength; skip for other communication modes).

2. Power on

Plug in the power supply.

3. Self-check process

After power-up, the red light turns on to indicate power activation, and the device enters self-check.

4. Normal Operation

Indicates local signal strength in four levels:

• Poor signal: Single red light flashes once every 1 minute.

• Moderate signal: Single red light flashes twice, repeated three times.

• Good signal: Single red light flashes three times, repeated three times.

• Excellent signal: Single red light flashes four times, repeated three times.

Install the device at the optimal signal location.

5. Fault Indications

NB-IoT Communication:

• Full-circle red light flashes 1x: NB module fault.

• Full-circle red light flashes 2x: NB card fault (check format, activation, or contact).

• Full-circle red light flashes 3x: Failed to connect to the base station (no internet access).

• Full-circle red light flashes 4x: Communication Failure with the platform (usually an identity verification issue).

Lora Communication:

• Red light flashes 2x: Module fault.

• Red light flashes 3x: Failed to join the network (possibly due to distance from the gateway, unpowered gateway, or unregistered device on the platform).

6. Alarm Test/Cancel

Press the button to test alarms (no alarm active) or cancel current alarms (alarm active).

7. Alarm Duration Adjustment

Default is 30s.

• First press: Display current duration (red light flashes: 1x=30s, 2x=5min, 3x=15min, 4x=30min).

• Second press: Switch to the next duration (cycles after 30min).

8. Volume Adjustment

Increase/decrease volume step-by-step via buttons (can also test functionality).

9. Heartbeat Interval Setting

Configurable via the platform.

10. Communication Failure

Red light flashes 3x every 1 hour.

Technical Parameters

• Power Supply: AC110V-240V

• Communication Current: <200mA

• Standby Current: <20mA

• Alarm Current: <300mA

• Operating Temperature: -10~+55℃

• Operating Humidity: <95%

• Alarm Volume: 110dB

• Alarm Duration: 30s/5min/15min/30min

• Heartbeat Interval: 2-24 hours

Precautions

1. This product uses 220V high voltage. Avoid direct contact with the power supply to prevent accidents.

2. Prohibited for children or untrained personnel.

3. Do not place in high-temperature/high-humidity environments, near heat sources, or under direct sunlight.

4. In case of malfunctions, do not disassemble the device; contact customer service immediately.

5. The manufacturer is not liable for faults or accidents caused by use outside the specified range.

6. The manufacturer is not liable for losses due to improper operation or losses exceeding the product’s value.

Non-Warranty Terms

1. Unauthorized repairs, misuse, collision, negligence, abuse, liquid ingress, accidents, modifications, or incorrect use of non-original accessories.

2. Tampering with or removing labels or anti-counterfeit marks.

3. Damage caused by force majeure.
